uDiscMounter - Driver Architecture

1. Introduction

uDiscMounter is a virtual drive system that allows a disk image (such as ISO) to be mounted as if it were a real physical CD/DVD device.

Unlike a normal application, the core functionality relies on a kernel-mode driver, which integrates directly with the Windows storage stack. This driver makes the operating system believe that a real storage device exists, even though all data actually comes from a file.

2. High-Level Architecture

The system is split into two main layers:

[ User Mode ]
---------------------------------
uDiscMounter Application
    |
    | IOCTL (DeviceIoControl)
    v

[ Kernel Mode ]
---------------------------------
uDiscMounter Driver
    |
    v
Windows Storage Stack
(File System → Class Driver → SCSI)

Key Idea

The driver emulates a CD-ROM device, and translates:

Disk Request (LBA-based)
        ↓
File Offset (inside ISO file)

3. Windows Storage Stack Integration

When a file is accessed from the mounted drive, the request flows through several layers:

Application (Read File)
        ↓
File System (CDFS / UDF)
        ↓
Class Driver (cdrom.sys)
        ↓
SCSI Request (SRB + CDB)
        ↓
uDiscMounter Driver
        ↓
ISO File (on disk)

4. SCSI Emulation Concept

Windows communicates with storage devices using SCSI commands.

Example: READ(10) command

CDB Structure:
---------------------------------
Byte 0  : Operation Code (0x28)
Byte 2-5: LBA (Logical Block Address)
Byte 7-8: Transfer Length

Your driver receives this and must respond as if it were real hardware.

5. Core Translation Logic

This is the heart of the system:

LBA (sector index)
        ↓
Offset = LBA * SectorSize (2048 for ISO)
        ↓
Read from ISO file
        ↓
Return data to OS

6. Driver Initialization (C++)

#include <ntddk.h>

NTSTATUS DriverEntry(PDRIVER_OBJECT DriverObject, PUNICODE_STRING RegistryPath)
{
    UNREFERENCED_PARAMETER(RegistryPath);

    DriverObject->MajorFunction[IRP_MJ_CREATE] = DispatchCreateClose;
    DriverObject->MajorFunction[IRP_MJ_CLOSE]  = DispatchCreateClose;
    DriverObject->MajorFunction[IRP_MJ_DEVICE_CONTROL] = DispatchDeviceControl;
    DriverObject->MajorFunction[IRP_MJ_SCSI] = DispatchScsi;

    DriverObject->DriverUnload = DriverUnload;

    IoCreateDevice(
        DriverObject,
        0,
        L"\\Device\\uDiscMounter",
        FILE_DEVICE_CD_ROM,
        0,
        FALSE,
        &g_DeviceObject
    );

    return STATUS_SUCCESS;
}

7. Mounting an Image

When the user mounts an ISO:

NTSTATUS OpenImageFile(PCWSTR path)
{
    OBJECT_ATTRIBUTES attr;
    IO_STATUS_BLOCK io;
    UNICODE_STRING uPath;

    RtlInitUnicodeString(&uPath, path);

    InitializeObjectAttributes(
        &attr,
        &uPath,
        OBJ_CASE_INSENSITIVE | OBJ_KERNEL_HANDLE,
        NULL,
        NULL
    );

    return ZwCreateFile(
        &g_ImageHandle,
        GENERIC_READ,
        &attr,
        &io,
        NULL,
        FILE_ATTRIBUTE_NORMAL,
        FILE_SHARE_READ,
        FILE_OPEN,
        FILE_NON_DIRECTORY_FILE,
        NULL,
        0
    );
}

8. Handling SCSI Requests

This is where the driver behaves like a real device.

NTSTATUS DispatchScsi(PDEVICE_OBJECT DeviceObject, PIRP Irp)
{
    PIO_STACK_LOCATION stack = IoGetCurrentIrpStackLocation(Irp);
    PSCSI_REQUEST_BLOCK srb = (PSCSI_REQUEST_BLOCK)stack->Parameters.Scsi.Srb;

    UCHAR op = srb->Cdb[0];

    switch (op)
    {
        case SCSIOP_READ:
        {
            ULONG lba =
                (srb->Cdb[2] << 24) |
                (srb->Cdb[3] << 16) |
                (srb->Cdb[4] << 8)  |
                (srb->Cdb[5]);

            ULONG sectors =
                (srb->Cdb[7] << 8) |
                (srb->Cdb[8]);

            LARGE_INTEGER offset;
            offset.QuadPart = (LONGLONG)lba * 2048;

            IO_STATUS_BLOCK io;

            ZwReadFile(
                g_ImageHandle,
                NULL,
                NULL,
                NULL,
                &io,
                srb->DataBuffer,
                sectors * 2048,
                &offset,
                NULL
            );

            srb->SrbStatus = SRB_STATUS_SUCCESS;
            Irp->IoStatus.Status = STATUS_SUCCESS;
            break;
        }

        default:
            srb->SrbStatus = SRB_STATUS_INVALID_REQUEST;
            Irp->IoStatus.Status = STATUS_NOT_SUPPORTED;
            break;
    }

    IoCompleteRequest(Irp, IO_NO_INCREMENT);
    return STATUS_SUCCESS;
}

9. Low-Level (Assembly Perspective)

At the lowest level, the operation becomes:

; Convert LBA to file offset

mov     rax, rcx        ; rcx = LBA
imul    rax, 2048       ; sector size

; Call ZwReadFile using offset

mov     rcx, g_ImageHandle
call    ZwReadFile

10. Unmount Process

When the drive is removed:

- Close ISO file (ZwClose)
- Remove symbolic link
- Delete device object
- Driver releases memory

11. Key Technical Characteristics

Runs in kernel mode
Emulates a SCSI CD-ROM device
Uses file-backed storage (ISO)
Translates LBA → file offset
Typically read-only
Integrates into Windows storage stack

12. Conclusion

uDiscMounter works by bridging two worlds:

The OS expects a hardware storage device
The driver provides a software-backed illusion

By implementing SCSI command handling and translating requests into file operations, the system achieves a seamless virtual drive experience.
